PRV Audio TW500My-Nd Pro Audio Super Tweeter
Free Shipping
Free standard shipping to Contiguous 48 US States
Free Returns
Learn More.
Features
This Neodymium Bullet Tweeter features a Mylar diaphragm for low distortion and extended high frequency response. The Mylar diaphragm is light, thin and durable for long play applications.
TW500My-Nd is designed with cast aluminum frame to ensure a quality sound and long lasting play in most any environment. Replacement Diaphragms available.
Highlights
- Type: Super Tweeter
- Nominal Impedance: 8 Ohms
- Rated AES Power Handling (RMS): 75 Watts
- Program Power: 150 Watts
- Voice Coil Diameter: 1.25?
GENERAL SPECIFICATIONS
Nominal impedance | 8 Ohms |
Rated AES Power Handling (RMS) | 75 Watts |
Program Power | 150 Watts |
Sensitivity 2.83V at 1m | 108 dB |
Recommended Hi Pass Crossover** **For Full Power Handling |
4000 Hz** **12db Per Octave Crossover |
Frequency Response at -10dB | 3,500 19,000 Hz |
Voice Coil Diameter | 1.25(32 mm) |
Voice Coil Wire | Aluminum |
Voice Coil Former Material | Kapton |
Diaphragm Material | Mylar |
Flux Density | 1.30 T |
Magnet Material | Neodymium |
EXTRA INFO
Overall Depth | 1.77 (45 mm) |
Mounting Depth | 1.61 (41 mm) |
Overall Diameter | 4.0 (100 mm) |
Cutout Diameter | 3.19 (81 mm) |
Net Weight | 1.25 lbs (0.56 kg) |
Shipping Weight | 1.33 lbs (0.60 kg) |
Carton Dimensions W x L x H | 4.1 x 4.1 x 2.1 (105 x 105 x 55 mm) |
